Universal line
Specification:
Pixel Pitch:
2.6 mm
LED Source:
SMD1515
Module type:
SCL layer / regular protective mask
Panel Size:
500x500mm / 19.7x19.7in
Panel Resolution:
192x192px
Panel Weight:
16lb
Drive IC / Scan:
ICN2153/24S
Refresh Rate:
7680Hz
Brightness:
800-1000Nits
Color Depth:
10-18bit (optional)
Receiving Card:
Novastar A8S plus
Input Voltage:
AC100-240V 50/60Hz
Max Power Consumption:
100W
Average Power Consumption:
50W
Working Temperature:
-40~140F
Working Humidity:
10-95%
Protection Rate:
IP44
Pixel Pitch:
2.976 mm
LED Source:
SMD1515
Module type:
SCL layer / regular protective mask
Panel Size:
500x500mm / 19.7x19.7in
Panel Resolution:
172x172px
Panel Weight:
16lb
Drive IC / Scan:
ICN2153/28S
Refresh Rate:
3840Hz
Brightness:
800-1000Nits
Color Depth:
10-18bit (optional)
Receiving Card:
Novastar A8S plus
Scanning Method:
1/21 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Max Power Consumption:
120W
Average Power Consumption:
≤60W
Protection Rate:
IP31
Maintenance Mode:
Front / Back
Pixel Pitch:
3.9 mm
LED Source:
SMD2121
Module type:
SCL layer / regular protective mask
Panel Size:
500x500mm / 19.7x19.7in
Panel Resolution:
128x128px
Panel Weight:
16lb
Drive IC / Scan:
ICN2153/16S
Refresh Rate:
3840Hz
Brightness:
800-1000Nits
Color Depth:
10-18bit (optional)
Receiving Card:
Novastar A8S plus
Scanning Method:
1/16 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Max Power Consumption:
≤120W
Average Power Consumption:
≤60W
Protection Rate:
IP31
Maintenance Mode:
Front / Back
Pixel Pitch:
3.9 mm
LED Source:
SMD2121
Module type:
SCL layer / regular protective mask
Panel Size:
500x500mm / 19.7x19.7in
Panel Resolution:
128x128px
Panel Weight:
16lb
Drive IC / Scan:
ICN2153/16S
Refresh Rate:
3840Hz
Brightness:
5000~5500Nits
Color Depth:
10-18bit (optional)
Receiving Card:
Novastar A8S plus
Scanning Method:
1/13 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Max Power Consumption:
≤300W
Average Power Consumption:
≤100W
Protection Rate:
IP56 / IP56
Maintenance Mode:
Front / Back
Pixel Pitch:
4.81 mm
LED Source:
SMD2121/SMD2525 (optional)
Module type:
SCL layer / regular protective mask
Panel Size:
500x500mm / 19.7x19.7in
Panel Resolution:
104x104px
Panel Weight:
16lb
Drive IC / Scan:
ICN2153/13S
Refresh Rate:
3840Hz
Brightness:
4700~5000Nits
Color Depth:
10-18bit (optional)
Receiving Card:
Novastar A8S plus
Scanning Method:
1/13 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Max Power Consumption:
≤300W
Average Power Consumption:
≤100W
Protection Rate:
IP56 / IP56
Maintenance Mode:
Front / Back
