Outdoor advertising sign
Specification:
Pixel Pitch:
10 mm
LED Source:
DIP
Module type:
Outdoor
Panel Size:
320x160mm / 12.6x6.3in
Panel Resolution:
32x16px
Panel Weight:
5.5lb
Refresh Rate:
2400Hz
Brightness:
7500-10000nits
Color Depth:
8-14bit (optional)
Driving method:
1/4
Receiving Card:
NovaStar A5S
Input Voltage:
AC100-240V 50/60Hz
Max Power Consumption:
40W
Average Power Consumption:
30W
Working Temperature:
-40~140F
Working Humidity:
10-95%
Protection Rate:
IP65
Pixel Pitch:
8 mm
LED Source:
DIP
Module type:
Outdoor
Panel Size:
320x160mm / 12.6x6.3in
Panel Resolution:
40x20px
Panel Weight:
5.5lb
Refresh Rate:
2400Hz
Brightness:
7500-10000nits
Color Depth:
8-14bit (optional)
Driving method:
1/4
Receiving Card:
NovaStar A5S
Input Voltage:
AC100-240V 50/60Hz
Max Power Consumption:
50W
Average Power Consumption:
35W
Working Temperature:
-40~140F
Working Humidity:
10-95%
Protection Rate:
IP65
Pixel Pitch:
6.7 mm
LED Source:
DIP
Module type:
Outdoor
Panel Size:
320x160mm / 12.6x6.3in
Panel Resolution:
48x24px
Panel Weight:
5.5lb
Refresh Rate:
2400Hz
Brightness:
7500-10000nits
Color Depth:
8-14bit (optional)
Driving method:
1/8
Receiving Card:
NovaStar A5S
Input Voltage:
AC100-240V 50/60Hz
Max Power Consumption:
50W
Average Power Consumption:
35W
Working Temperature:
-40~140F
Working Humidity:
10-95%
Protection Rate:
IP65
