M line
Specification:
Pixel Pitch:
1.25 mm
LED Source:
SMD1010
Module Size:
320x160mm / 12.6x6.3in
Module Resolution:
256x128px
Module Weight:
0.5lb
Refresh Rate:
≥3840Hz
Brightness:
≥900nits
Color Depth:
10-16bit (optional)
Receiving Card:
NovaStar MRV328/216
Scanning Method:
1/64 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Average Power Consumption:
≤20W
Max Power Consumption:
≤30W/SQM
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
1.53 mm
LED Source:
SMD1212
Module Size:
320x160mm / 12.6x6.3in
Module Resolution:
208x104px
Module Weight:
0.5lb
Refresh Rate:
≥3840Hz
Brightness:
≥900nits
Color Depth:
10-18bit (optional)
Receiving Card:
NovaStar MRV328/216
Scanning Method:
1/52 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Average Power Consumption:
≤20W
Max Power Consumption:
≤30W/SQM
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
1.66 mm
LED Source:
SMD1212
Module Size:
320x160mm / 12.6x6.3in
Module Resolution:
192x96px
Module Weight:
0.5lb
Refresh Rate:
≥3840Hz
Brightness:
≥900nits
Color Depth:
10-18bit (optional)
Receiving Card:
NovaStar MRV328/216
Scanning Method:
1/48 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Average Power Consumption:
≤20W
Max Power Consumption:
≤30W/SQM
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
1.86 mm
LED Source:
SMD1515
Module Size:
320x160mm / 12.6x6.3in
Module Resolution:
172x86px
Module Weight:
0.5lb
Refresh Rate:
≥3840Hz
Brightness:
≥900nits
Color Depth:
10-18bit (optional)
Receiving Card:
NovaStar MRV328/216
Scanning Method:
1/43 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Average Power Consumption:
≤20W
Max Power Consumption:
≤30W/SQM
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
2.0 mm
LED Source:
SMD1515
Module Size:
320x160mm / 12.6x6.3in
Module Resolution:
160x80px
Module Weight:
0.5lb
Refresh Rate:
≥3840Hz
Brightness:
≥900nits
Color Depth:
10-18bit (optional)
Receiving Card:
NovaStar MRV328/216
Scanning Method:
1/40 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Average Power Consumption:
≤20W
Max Power Consumption:
≤30W/SQM
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
2.5 mm
LED Source:
SMD1515
Module Size:
320x160mm / 12.6x6.3in
Module Resolution:
128x64px
Module Weight:
0.5lb
Refresh Rate:
≥7680Hz
Brightness:
≥900nits
Color Depth:
10-18bit (optional)
Receiving Card:
NovaStar A8s
Scanning Method:
1/16 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Average Power Consumption:
≤20W
Max Power Consumption:
≤30W/SQM
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
3.3 mm
LED Source:
SMD2020
Module Size:
320x160mm / 12.6x6.3in
Module Resolution:
96x48px
Module Weight:
0.5lb
Refresh Rate:
≥3840Hz
Brightness:
≥900nits
Color Depth:
10-18bit (optional)
Receiving Card:
NovaStar MRV328/216
Scanning Method:
1/24 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Average Power Consumption:
≤20W
Max Power Consumption:
≤30W/SQM
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
4.0 mm
LED Source:
SMD2020
Module Size:
320x160mm / 12.6x6.3in
Module Resolution:
80x40px
Module Weight:
0.5lb
Refresh Rate:
≥3840Hz
Brightness:
≥900nits
Color Depth:
10-18bit (optional)
Receiving Card:
NovaStar MRV328/216
Scanning Method:
1/20 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Average Power Consumption:
≤20W
Max Power Consumption:
≤30W/SQM
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
5.0 mm
LED Source:
SMD2121
Module Size:
320x160mm / 12.6x6.3in
Module Resolution:
256x128px
Module Weight:
0.5lb
Refresh Rate:
≥3840Hz
Brightness:
≥900nits
Color Depth:
10-16bit (optional)
Receiving Card:
NovaStar MRV328/216
Scanning Method:
1/64 Scanning Constant Current
Input Voltage:
AC110-240V 50/60Hz
Average Power Consumption:
≤20W
Max Power Consumption:
≤30W/SQM
Protection Rate:
IP31
Maintenance Mode:
Front
