FSP line
Specification:
Pixel Pitch:
1.87 mm
LED Source:
SMD1515
Panel Size:
640x480mm / 18.9x21.21in
Panel Resolution:
256x288px
Panel Weight:
18lb
Refresh Rate:
≥3840Hz
Brightness:
900~1500nits
Color Depth:
16bit
Receiving Card:
NovaStar A5S/A8S
Scanning Method:
1\32 Scanning Constant Current
Input Voltage:
AC110-220V 50/60Hz
Max Power Consumption:
130W
Average Power Consumption:
70W
Module Quantity:
2x3pcs
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
2.0 mm
LED Source:
SMD1515
Panel Size:
640x480mm / 18.9x21.21in
Panel Resolution:
240x270px
Panel Weight:
18lb
Refresh Rate:
≥3840Hz
Brightness:
900~1500nits
Color Depth:
16bit
Receiving Card:
NovaStar A5S/A8S
Scanning Method:
1\32 Scanning Constant Current
Input Voltage:
AC110-220V 50/60Hz
Max Power Consumption:
130W
Average Power Consumption:
70W
Module Quantity:
2x3pcs
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
2.5 mm
LED Source:
SMD1515
Panel Size:
640x480mm / 18.9x21.21in
Panel Resolution:
256x192px
Panel Weight:
18lb
Refresh Rate:
≥7680Hz
Brightness:
900~1500nits
Color Depth:
18bit (optional)
Receiving Card:
NovaStar A10Pro
Scanning Method:
1\16 Scanning Constant Current
Input Voltage:
AC110-220V 50/60Hz
Max Power Consumption:
130W
Average Power Consumption:
68W
Module Quantity:
2x3pcs
Protection Rate:
IP31
Maintenance Mode:
Front
Pixel Pitch:
3.0 mm
LED Source:
SMD1515
Panel Size:
640x480mm / 18.9x21.21in
Panel Resolution:
160x180px
Panel Weight:
18lb
Refresh Rate:
≥3840Hz
Brightness:
900~1500nits
Color Depth:
16bit
Receiving Card:
NovaStar A5S
Scanning Method:
1\30 Scanning Constant Current
Input Voltage:
AC110-220V 50/60Hz
Max Power Consumption:
130W
Average Power Consumption:
68W
Module Quantity:
2x3pcs
Protection Rate:
IP31
Maintenance Mode:
Front
