Rigid Module Line

SPN-03 (special design)

See the specs

Specification

Model:  SPN-03 (special design)
Voltage:  DC-24V
LED:  SMD3535
Power:  5.3W
Dimension:  6.5x1x0.63in (650x31x16.5mm)
Color Temperature:  White 2700-13000K
Beam Angle:  13-60*
IP Rate:  IP65
Unit Price:  $11.70

SPN-06 (special design)

See the specs

Specification

Model:  SPN-06 (special design)
Voltage:  DC-24V
LED:  SMD3535
Power:  9.7W
Dimension:  12.8x1x0.63in (325x25x16.5mm)
Color Temperature:  White 2700-13000K
Beam Angle:  13-60*
IP Rate:  IP65
Unit Price:  $15.00

LRB-S3535/06P

See the specs

Specification

Model:  LRB-S3535/06P
Voltage:  DC-24V
LED:  SMD3535
Power:  14.4W
Dimension:  19.7x1.25x0.63in (500x32x16.5mm)
Color Temperature:  White 13000-14700K
Beam Angle:  10-45*
IP Rate:  IP68
Unit Price:  $18.00

LRB-S3535/12P

See the specs

Specification

Model:  LRB-S3535/12P
Voltage:  DC-24V
LED:  SMD3535
Power:  28.8W
Dimension:  39.4x1.25x0.63in (1000x32x16.5mm)
Color Temperature:  White 13000-14700K
Beam Angle:  10-45*
IP Rate:  IP68
Unit Price:  $33.8

LRB-S3030/09P cuttable

See the specs

Specification

Model:  LRB-S3030/09P cuttable
Voltage:  DC-24V
LED:  EMC3030
Power:  11.5W
Dimension:  25.6x1.22x0.63in (650x31x16.5mm)
Color Temperature:  White 2700-13000K
Beam Angle:  15-60*
IP Rate:  IP65
Unit Price:  $11.70

LRB-S3030/18P cuttable

See the specs

Specification

Model:  LRB-S3030/18P cuttable
Voltage:  DC-24V
LED:  EMC3030
Power:  23W
Dimension:  51.2x1.22x0.63in (1150x31x16.5mm)
Color Temperature:  White 2700-13000K
Beam Angle:  15-60*
IP Rate:  IP65
Unit Price:  $21.80

LRB-S2835/60

See the specs

Specification

Model:  LRB-S2835/60
Voltage:  DC-12V
LED:  SMD2835
Power:  9.6W
Dimension:  39.4x0.16x0.08in (1000x4x2.4mm)
Color Temperature:  White 2700-13000K
Beam Angle:  120*
IP Rate:  IP20
Unit Price:  $3.64

LRB-S2835/90

See the specs

Specification

Model:  LRB-S2835/90
Voltage:  DC-12V
LED:  SMD2835
Power:  14.4W
Dimension:  39.4x0.16x0.08in (1000x4x2.4mm)
Color Temperature:  White 2700-13000K
Beam Angle:  120*
IP Rate:  IP20
Unit Price:  $4.16

LRB-S2835/120

See the specs

Specification

Model:  LRB-S2835/120
Voltage:  DC-12V
LED:  SMD2835
Power:  16.8W
Dimension:  39.4x0.16x0.08in (1000x4x2.4mm)
Color Temperature:  White 2700-13000K
Beam Angle:  120*
IP Rate:  IP20
Unit Price:  $4.94

LB-B3030/06 cuttable

See the specs

Specification

Model:  LB-B3030/06 cuttable
Voltage:  DC-24V
LED:  EMC3030
Power:  7.9W
Dimension:  19.5x0.71x0.27in (495x18x7.1mm)
Color Temperature:  White 2700-13000K
Beam Angle:  170*
IP Rate:  IP20
Unit Price:  $5.56

LB-B3030/12 cuttable

See the specs

Specification

Model:  LB-B3030/12 cuttable
Voltage:  DC-24V
LED:  EMC3030
Power:  15.8W
Dimension:  39x0.71x0.27in (990x18x7.1mm)
Color Temperature:  White 2700-13000K
Beam Angle:  170*
IP Rate:  IP20
Unit Price:  $7.93

LB-B3030/06P cuttable

See the specs

Specification

Model:  LB-B3030/06P cuttable
Voltage:  DC-24V
LED:  EMC3030
Power:  7.9W
Dimension:  19.7x0.9x0.55in (500x18x7.1mm)
Color Temperature:  White 2700-13000K
Beam Angle:  170*
IP Rate:  IP65
Unit Price:  $9.30

LB-B3030/12P cuttable

See the specs

Specification

Model:  LB-B3030/12P cuttable
Voltage:  DC-24V
LED:  EMC3030
Power:  15.8W
Dimension:  39.4x0.9x0.55in (1000x18x7.1mm)
Color Temperature:  White 2700-13000K
Beam Angle:  170*
IP Rate:  IP65
Unit Price:  $12.55

LB-D3030/12P cuttable

See the specs

Specification

Model:  LB-D3030/12P cuttable
Voltage:  DC-24V
LED:  EMC3030
Power:  14.4W
Dimension:  19.8x0.9x0.55in (500x23x14mm)
Color Temperature:  White 2700-13000K
Beam Angle:  170*
IP Rate:  IP65
Unit Price:  $11.00

LB-B3030/24P cuttable

See the specs

Specification

Model:  LB-B3030/24P cuttable
Voltage:  DC-24V
LED:  EMC3030
Power:  28.8W
Dimension:  39.6x0.9x0.55in (1000x23x14mm)
Color Temperature:  White 2700-13000K
Beam Angle:  170*
IP Rate:  IP65
Unit Price:  $18.00

LB-IC2835/12 cuttable

See the specs

Specification

Model:  LB-IC2835/12 cuttable
Voltage:  DC-24V
LED:  SMD2835
Power:  5W
Dimension:  18.9x0.63x0.08in (480x16x2.5mm)
Color Temperature:  White 2700-13000K
Beam Angle:  120*
IP Rate:  IP20
Unit Price:  $5.20

LB-IC2835/24 cuttable

See the specs

Specification

Model:  LB-IC2835/24 cuttable
Voltage:  DC-24V
LED:  SMD2835
Power:  10W
Dimension:  37.8x0.63x0.08in (960x16x2.5mm)
Color Temperature:  White 2700-13000K
Beam Angle:  120*
IP Rate:  IP20
Unit Price:  $8.80
Download price PDF
